Dyness Tower T10 Battery 288V 10.66kWh LiFePO4
Modelo: Tower T10- Sku: DYNEBAT006
- Vendor: Dyness
Specifications
Product description
The Dyness Tower T10 288V 10.66kWh LiFePO4 Battery is a high voltage (HV) solution designed for three-phase self-consumption and demanding hybrid systems. With three stacked modules and 10.66 kWh usable, it integrates a master BMS, industrial communications (CAN/RS485/RS232), and an IP54 enclosure suitable for indoor/outdoor use. Delivers up to 0.6 C continuously (≈6.39 kW) and allows for energy and power growth by connecting towers in parallel, maintaining the safety and stability of LiFePO₄ chemistry.
Main features
- True HV architecture: 288 V nominal (range 252–328 V) for three-phase inverters.
- Energy per tower: 10.66 kWh usable with 3 modules and 37 Ah capacity.
- Continuous power: 0.6 C ≈ 6.39 kW per tower with BMS control.
- Connectivity: CAN/RS485/RS232 with Dyness profile for native integration.
- IP54 installation: indoor/outdoor use, floor base and hardware included.
- Scalability: up to 4 towers in parallel to increase the system's kWh and kW.
Advantages or benefits
- Higher inverter efficiency by operating at high voltage, with lower currents and losses.
- LFP safety: thermal stability, low degradation, and thousands of useful cycles.
- Rapid deployment: module auto-configuration, monitoring APP, and remote update.
- Service continuity: BMS with protections (OV/UV, OC, OT/UT, short circuit) and active balancing.
- Scalable project: add towers to cover future expansions without redoing the installation.
Purpose or applications
Ideal for high-consumption residential and light C&I in three-phase on-grid self-consumption with backup, peak-shaving, and off-grid solutions (depending on inverter). Not compatible with 48 V LV ecosystems.
Technical specifications
| Usable energy | 10.66 kWh |
| Nominal voltage | 288 V (range 252–328 V) |
| Capacity | 37 Ah |
| Continuous power | 0.6 C ≈ 6.39 kW (with communication) |
| Modules per tower | 3 |
| Communication | CAN / RS485 / RS232 (Dyness profile) |
| Parallel | Up to 4 towers |
| Protection | IP54 (indoor/outdoor) |
| Temperature | Charge 0…+50 °C · Discharge −10…+50 °C |
| Chemistry | LiFePO₄ (LFP) |
Compatibilities
Requires HV inverters with Dyness profile via CAN/RS485/RS232. Common compatibility with Deye/SUN, GoodWe, Solis, Kostal, Ingeteam, SAJ, Sunways, eCactus three-phase families, among others (consult official lists). Not compatible with 48 V single-phase inverters or LV banks.
Dyness Tower T10 288V 10.66kWh LiFePO4 Battery is a professional solution for demanding renewable energy projects. Increases autonomy, optimizes space, and improves the efficiency of your installation.
