Pylontech Force H1 High Voltage Lithium Battery 21.31kWh 288V with BMS
Modelo: Force H1 21,31kWh 288V- Sku: PYLOBAT018
- Vendor: Pylontech
Specifications
Product Description
The Pylontech Force H1 21.31kWh 288V HV Lithium Battery with BMS is designed for projects requiring greater autonomy and sustained power. With 6 FH48074 modules of 3.55 kWh each and the BMS FC0500-40S, it forms a high-voltage stack of 288 V, optimal for three-phase HV hybrid inverters. The LiFePO4 chemistry offers superior safety and long service life, while CAN/RS485 communication ensures precise telemetry and coordination with the inverter.
Main Features
- System capacity: 21.31 kWh (6× FH48074 in series).
- Nominal voltage: 288 V for high-efficiency HV buses.
- LFP chemistry: thermal stability, low degradation, and thousands of cycles.
- BMS FC0500-40S with balancing, SoC/SoH, and comprehensive protections.
- CAN/RS485 communication for native integration with HV hybrids.
- Modular rack Force H1 architecture: expandable, organized, and minimal maintenance.
Advantages or Benefits
- High autonomy: 21.31 kWh to cover long nights and intensive consumption.
- Superior electrical efficiency: lower current in HV → lower losses and better inverter utilization.
- Comprehensive safety: protections for voltage, current, temperature, and short circuit.
- Scalability: possibility to expand to 24.86 kWh without altering the architecture.
- Professional integration: clear telemetry and stable response with three-phase HV inverters.
Purpose or Applications
High-consumption homes, businesses, offices, and three-phase applications that require service continuity, time-of-use arbitrage, and peak demand reduction. Excellent base for critical load backup and system stability in networks with incidents.
Technical Specifications
| System energy | 21.31 kWh (6× 3.55 kWh) |
| Nominal voltage | 288 V (HV) |
| Chemistry | LiFePO4 (LFP) |
| Number of modules | 6× FH48074 in series |
| BMS | FC0500-40S (included) |
| Communication | CAN / RS485 to inverter |
| Protections | OV/UV, OC, temperature, short circuit, balancing |
| Protection rating | IP20 (indoor use, rack) |
| Operating temperature | Charge 0–50 °C · Discharge −10–50 °C |
| Life cycles | High (typical DoD, 25 °C) |
| Dimensions / weight | Stacked Force H1 assembly (see official diagram) |
| Warranty | Up to 10 years (according to manufacturer) |
Compatibilities
Native system with FH48074 and FC0500-40S. Integration with HV hybrid inverters via CAN/RS485 (consult official list by model). Accessories: Force H1 base/rack, specific cabling, and hardware.
The Pylontech Force H1 21.31kWh 288V HV Lithium Battery with BMS offers a high-performance, reliable HV platform to take your energy storage to a professional level with total safety and control.
