Lorentz PS2-200 HRE-04 0.73 m³/h 50 m helical submersible solar pump with controller
Modelo: 02-001100 PS2-200 HRE-04- Sku: LOREBOM078
- Vendor: Lorentz
Specifications
Product Description
The Lorentz PS2-200 HRE-04 Submersible Solar Pump is a complete system for 4” wells that prioritizes efficiency and simplicity. It integrates the PS2-200 controller with MPPT, a brushless ECDrive motor, and the HRE-04 helical head in AISI 304/316 with a non-return valve. It offers a reference flow rate of 0.73 m³/h and a head of up to 50 m, ideal for domestic supply, tank filling, and drip irrigation with very low solar consumption.
Main Features
- Reference head up to 50 m with a flow rate of 0.73 m³/h.
- PS2-200 controller with MPPT to maximize the energy from the panels.
- Submersible ECDrive motor, IP68, high efficiency and minimal maintenance.
- HRE-04 helical hydraulics in AISI 304/316 with integrated non-return valve.
- Inputs for dry well protection and tank control; reliable and safe operation.
Advantages or Benefits
- Economical and efficient solution for moderate flow rates and medium heads.
- Simple and modular installation with spare parts and support from the Lorentz ecosystem.
- Reduced operating costs due to its brushless design and MPPT management.
- Greater hydraulic protection and system lifespan thanks to the integrated valve.
Purpose or Applications
Isolated homes, small farms, tanks at moderate elevation, and localized irrigation. Excellent option when you want to maximize autonomy with a small PV array.
Technical Specifications
| Reference Head / Flow Rate | Up to 50 m / 0.73 m³/h |
| Controller | PS2-200 with MPPT and integrated protections |
| Motor | ECDrive series 200, brushless, IP68 |
| Hydraulics | PE HRE-04 helical with non-return valve |
| Materials in contact | Stainless steel AISI 304/316 |
| Well diameter | ≥ 4” |
| Water temperature | ≤ 50 °C (typical) |
| Protection rating | IP68 (submersible unit) |
Compatibilities
Compatible with photovoltaic arrays from multiple brands as long as they meet the controller’s electrical limits (input voltage/current and MPPT window). Recommended accessories: dry well and tank probes, DC protections, submersible cable, and riser pipe.
The Lorentz PS2-200 HRE-04 Submersible Solar Pump offers reliable performance, efficiency, and ease of integration for small and medium-sized solar pumping projects.
