Lorentz PS2-200 HRE-07 1.3m³/h 40m Helical Submersible Solar Pump with Controller

Modelo: 02-001110 PS2-200 HRE-07

Sku: LOREBOM079
Vendor: Lorentz

€2.102,08 EUR

€1.681,67 EUR

Tax included.

Shipping calculated at checkout.

In stock!

Spend €150,00 to FREE SHIPPING

The Lorentz PS2-200 HRE-07 Submersible Solar Pump delivers 1.3 m³/h with 40 m head. Complete system with MPPT PS2-200 controller, ECDrive 200-HRE IP68 motor, and HRE-07 hydraulics in AISI 304/316 for 4” wells.

Product variants

Quantity

I agree with the Terms and Conditions.

Purchase with Secure Payment

Specifications

Product Description

The Lorentz PS2-200 HRE-07 1.3 m³/h 40 m helical Submersible Solar Pump with controller is designed for projects requiring maximum efficiency with small photovoltaic arrays. The system integrates the PS2-200 MPPT controller, the brushless ECDrive 200-HRE motor, and the helical hydraulics HRE-07, achieving flow rates of 1.3 m³/h with heads up to 40 m in 4” wells. The combination of AISI 304/316 stainless steel materials, IP68 protection, and electronics optimized for solar ensures reliable, silent operation with minimal maintenance.

Main Features

Flow/head: 1.3 m³/h and 40 m, ideal for tanks, drip irrigation, and domestic supply.
PS2-200 Controller with MPPT, soft start, and probe management.
PV input: max. power 0.30 kW; max. input voltage 100 V; optimal Vmp > 34 V.
ECDrive 200-HRE Motor with high efficiency, sealed and IP68 for continuous operation.
HRE-07 Hydraulics with integrated check valve; max. hydraulic efficiency ~70%.
Typical maximum immersion 150 m (depending on installation and cabling); clean water up to 50 °C.

Advantages or Benefits

Outstanding performance with low solar power thanks to MPPT and helical hydraulics.
Simple and safe installation: supports well probe, full tank, and remote control.
Reduced total cost: brushless motor, minimal intervention, and long service life.
Silent and reliable: sealed IP68 design for continuous operation in remote environments.
Scalable: allows expansion of the PV generator while maintaining the electronics and pump.

Purpose or Applications

Supply for isolated homes, filling of storage tanks, livestock watering, and localized irrigation in plots with moderate pressure demands. Very suitable when the available PV array is limited and constant water is needed during sunlight hours.

Technical Specifications

Maximum flow	1.3 m³/h
Maximum head	40 m
Controller	PS2-200 with MPPT and interfaces for probes/remote
Max. PV power	0.30 kW
Max. input voltage	100 V DC
Optimal Vmp	> 34 V
Motor	ECDrive 200-HRE, brushless, IP68
Hydraulics	PE HRE-07 helical, AISI 304/316, check valve, max. η ~70%
Well diameter	≥ 4”
Water temperature	≤ 50 °C (clean water)
Protections	Reverse polarity, overload, overtemperature; dry running via probe

Compatibilities

Compatible with photovoltaic arrays meeting Vmp > 34 V and the controller limits (≤ 100 V / ≤ 0.30 kW). Direct integration with well and tank level sensors, pressure switches, or external control. Applicable to supply and irrigation systems where the specified flow/head is required.

The Lorentz PS2-200 HRE-07 1.3 m³/h 40 m combines intelligent control, brushless motor, and high-performance helical hydraulics to guarantee daily water supply with solar energy and minimal operating cost.
