Lorentz PS2-600 HRE-14 Submersible Solar Pump 2.6 m³/h 50 m helical with controller
Modelo: 03-010340 PS2-600 HRE-14- Sku: LOREBOM091
- Vendor: Lorentz
Specifications
Product Description
The Lorentz PS2-600 HRE-14 2.6 m³/h 50 m Helical Submersible Solar Pump with Controller is a professional, ready-to-use solution that combines the PS2-600 MPPT controller, ECDrive 600-HRE brushless motor, and HRE-14 helical hydraulics. It delivers up to 2.6 m³/h with 50 m head, high efficiency, and IP68 reliability for 4” wells.
Main Features
- Flow/Head: up to 2.6 m³/h and 50 m.
- PS2-600 Controller with MPPT, inputs for dry-run protection, full tank, and remote control.
- PV Input: max. power 0.70 kW, max. input voltage 150 V, optimal Vmp > 68 V.
- ECDrive 600-HRE Motor brushless, sealed, minimal maintenance, IP68.
- PE HRE-14 Hydraulics helical in AISI 304/316 stainless steel with integrated check valve.
- Approximate maximum hydraulic efficiency 63 %; maximum submersion 150 m.
Advantages or Benefits
- More water per day with the same PV array thanks to MPPT and helical hydraulics.
- Quick and safe installation: integrated controller with protections and probe inputs.
- Robustness for intensive use: IP68 brushless motor and AISI 304/316 materials.
- Low operating cost: high efficiency and minimal maintenance.
- Scalable and adaptable according to irradiation and water demand.
Purpose or Applications
Perfect for domestic supply in off-grid homes, drip or light sprinkler irrigation, transfer to tanks, and livestock, especially in 4” wells with medium pressure requirements.
Technical Specifications
| Max. flow | 2.6 m³/h |
| Max. head | 50 m |
| Max. PV power | 0.70 kW |
| Max. input voltage | 150 V DC |
| Optimal Vmp | > 68 V |
| Controller | PS2-600 with MPPT, inputs for probes/remote |
| Motor | ECDrive 600-HRE, brushless, IP68 |
| Hydraulics | PE HRE-14, helical, AISI 304/316, check valve |
| Max. submersion | 150 m |
| Protection rating | IP68 (submersible unit) |
Compatibilities
Compatible with photovoltaic arrays meeting Vmp > 68 V and the controller’s 150 V / 0.70 kW limits. Integrable with level sensors, tank switches, and automation. Applicable to supply systems, irrigation, and elevated tanks, provided flow and head requirements are met.
The Lorentz PS2-600 HRE-14 Submersible Solar Pump provides reliable water with solar energy, intelligent control, and premium construction designed to last.
