DC Surge Protector SMA DC-SPD-KIT4-10 Core1 Type 2

Product Description

The SMA DC-SPD-KIT4-10 is a Type 2 (Class II) direct current surge protection device, manufactured by Raycap (model ProTec T2-1100PV). It has been specifically designed for direct integration into the SMA Sunny Tripower CORE1 inverter, effectively protecting PV strings against surges induced by lightning or grid switching.

Main Features

• Type 2 SPD up to 1100 VDC, 50 kA total discharge
• Multipolar pluggable design for easy replacement
• Compatible with SMA CORE1 inverter (internal mounting)
• Protection in mode (+)–PE, (–)–PE and (+)–(–)
• Optional version with remote fault contact (RC)

Advantages or Benefits

• Reliable protection against surges induced by storms or grid operations
• Direct installation in the internal space of the CORE1 inverter
• Visual indicator for immediate status diagnosis
• Can also be used in external string boxes with DIN rail
• Complies with IEC, UL, and REBT (ITC-BT-40) standards

Purpose or Applications

This surge protection device is intended for commercial or industrial photovoltaic installations using SMA CORE1 STP 50-40 inverters. Ideal in environments where protection against induced surges is required, but Type 1 protection is not mandatory. It can also be integrated into external string boxes with standard DIN rail.

Technical Specifications

Compatibilities

This product is compatible with: SMA Sunny Tripower CORE1 STP 50-40.

SMA DC-SPD-KIT4-10 is the ideal option when effective and cost-efficient protection against induced surges in solar strings is required. Its quick installation and pluggable design make it a practical, safe solution that complies with international standards.
