DC Surge Arrester SMA DC-SPD-KIT5-T1T2 Core1 Type 1+2
Modelo: DC-SPD-KIT5-T1T2- Sku: SMAACCE008
- Vendor: SMA
Specifications
Product description
The SMA DC-SPD-KIT5-T1T2 is a direct current surge arrester of Type 1+2 (Class I+II), developed specifically for integration in the three-phase inverter SMA Sunny Tripower CORE1. This advanced protection kit safeguards against direct and indirect surges, ensuring the safety and continuity of the photovoltaic installation even in areas with a high risk of lightning strikes.
Main features
- Type 1+2 SPD arrester for DC up to 1100 VDC
- Exclusive design for SMA CORE1 STP 50-40
- Direct mounting in the internal space of the inverter
- Integrated monitoring via the inverter electronics
- Total protection of PV strings (PV+, PV– and PE)
Advantages or benefits
- Robust protection against direct lightning strikes and induced overvoltages
- No need for external panels or additional wiring
- Quick and safe installation, without modifying the inverter
- SPD status monitoring from the CORE1 platform
- Allows compliance with electrical regulations such as ITC-BT-40 or REBT in risk areas
Purpose or applications
This surge arrester is recommended for commercial or industrial photovoltaic installations using the SMA CORE1 STP 50-40 inverter, especially in areas with a high risk of lightning strikes or sensitive environments. Ideal for projects on flat roofs or solar parks where regulations require Type 1+2 SPD protection on the DC side.
Technical specifications
| Type / Class | SPD Type 1+2 (Class I+II) |
| Use | Protection on inverter DC inputs (PV+) |
| Number of modules | 9 DIN modules (6 PV+, 2 PV–, 1 PE) |
| Mounting | Internal to the CORE1 inverter (reserved space) |
| Ethernet protection | Not included (can be added externally) |
| AC protection | Requires additional kit (AC-SPD-KIT-10) |
| Monitoring | ✅ Internal electronic path of the CORE1 inverter |
| Maximum voltage | 1100 VDC |
| Standards | IEC/EN 61643-31, UL 1449 Ed.4 |
| Certifications | CE, UL |
Compatibilities
This product is compatible with: SMA Sunny Tripower CORE1 STP 50-40.
SMA DC-SPD-KIT5-T1T2 is the ultimate protection for the CORE1 inverter. It enhances the safety of your installation against direct lightning strikes, with no installation complications or loss of functionality. Compatible, certified, and designed to last.
