Inverter with Charger Victron MultiPlus C 12V 2000VA 12/2000/80-30
Modelo: Multiplus C 12/2000/80-30- Sku: VICTINV009
- Vendor: Victron
Specifications
Product Description
The Victron MultiPlus C 12V 2000VA 12/2000/80-30 represents a leap in capacity within the MultiPlus C range, combining a pure sine wave inverter of 2000 VA with a powerful 80 A charger and a 30 A transfer system. It is designed for 12 V projects that require greater continuous power margin and high start-up peaks, maintaining the Victron philosophy: high efficiency, intelligent control, and a sector-leading monitoring ecosystem.
Main Features
- Inverter power: 2000 VA (≈1600 W continuous at 25 °C); peak ≈4000 W.
- Integrated 80 A charger with multi-stage curve and profiles for lithium and lead-acid.
- Automatic switching of 30 A (“-30” code), ideal as UPS for critical loads.
- PowerControl/PowerAssist to limit grid/generator input and support peaks from the battery.
- VE.Bus interface for advanced configuration, parallel operation, and connection to Cerbo GX/VRM.
- Robust construction, optimized dissipation, and reduced idle consumption with search mode.
Advantages or Benefits
- Professional continuity: fast transfer avoids interruptions in sensitive electronics.
- Greater usable power: supports demanding tools and appliances with high peaks.
- Intelligent energy management: prevents tripping of circuit breakers and generator overloads.
- Total integration: monitor and adjust parameters from VictronConnect and the VRM portal.
- Long battery life: optimized charging algorithms and fine adjustments by technology.
Purpose or Applications
Perfect for campers and boats with several simultaneous consumers, off-grid homes with refrigerators, light tools or pumps, micro data/telecom centers, and as a domestic UPS in 12 V systems requiring 30 A transfer.
Technical Specifications
| Inverter power | 2000 VA (≈1600 W at 25 °C); peak ≈4000 W |
| Battery voltage | 12 Vdc |
| Charger | 80 A; Abs ≈14.4 V / Float ≈13.8 V / Storage ≈13.2 V |
| Switching | Transfer 30 A; typical time <20 ms (UPS mode) |
| Waveform | Pure sine wave 230 V / 50 Hz |
| Efficiency | ≈94 % |
| Idle consumption | ≈10–12 W (search mode ≈2–3 W) |
| Communications | VE.Bus; integration with Cerbo GX and VRM portal |
| Protections | Overload, short circuit, high/low V, temperature, etc. |
| Degree of protection | IP20 (indoor) |
| Dimensions / Weight | ≈520 × 255 × 125 mm / ≈12 kg |
| Operating temperature | −40 … +65 °C (derating with temperature) |
| Battery compatibility | AGM, GEL and lithium (adjustable) |
Compatibilities
Accessories and ecosystem: Cerbo GX, VE.Bus Smart Dongle, Multi Control Digital Panel, MK3-USB interface, BMV-712/SmartShunt monitors, VictronConnect app and VRM portal. (The second AC output is available from the 3 kVA range onwards, not in this version).
If you are looking for a robust 12 V system ready for demanding tasks, the Victron MultiPlus C 12V 2000VA 12/2000/80-30 delivers real power, advanced management, and the recognized reliability of Victron.
