Inverter with Charger Victron MultiPlus C 12V 800VA 12/800/35-16
Modelo: Multiplus C 12/800/35-16- Sku: VICTINV006
- Vendor: Victron
Specifications
Product Description
The Victron MultiPlus C 12V 800VA 12/800/35-16 combines a pure sine wave inverter and battery charger in a single compact unit, ideal for caravans, boats, and small off-grid installations. It integrates PowerControl/PowerAssist to manage available power and a fast transfer system that acts as a UPS, ensuring service continuity even with sensitive electronic loads.
Main Features
- Rated power: 800 VA (700 W at 25 °C), peak 1600 W for startups.
- Integrated 12 V, 35 A charger with absorption, float, and storage stages.
- Automatic switching of 16 A with typical transfer time <20 ms.
- PowerAssist and PowerControl functions to add battery power when the grid/generator is limited.
- VE.Bus communications for remote control, parallel operation, and monitoring with Cerbo GX/VRM.
- High efficiency (≈92–94%), very low standby consumption with saver/search mode.
Advantages or Benefits
- Flicker-free continuity: protects IT equipment, routers, and sensitive electronics.
- Peak management: prevents generator or grid trips by supplementing power with the battery.
- Easy installation: compact format, accessible terminals, and charging profiles for AGM, GEL, and lithium.
- Scalable: allows parallel operation and advanced control via Victron devices.
- Energy efficiency: reduces unnecessary consumption thanks to saver and search modes.
Purpose or Applications
Recommended for use in caravans and campers, small boats, site cabins, low-demand telecommunications, powering critical equipment in self-consumption homes, or as a UPS in 12 V installations.
Technical Specifications
| Inverter power | 800 VA (700 W at 25 °C); peak 1600 W |
| Battery voltage | 12 Vdc |
| Charger | 35 A; Abs 14.4 V / Float 13.8 V / Storage 13.2 V |
| Switching | Transfer 16 A; UPS <20 ms |
| Efficiency | ≈92–94 % |
| No-load consumption | 8–10 W (search 2–3 W) |
| Communications | VE.Bus; remote on/off |
| Protection | Overload, short circuit, high/low voltage, temperature |
| Degree of protection | IP20 |
| Dimensions / Weight | 375×214×110 mm / 10 kg |
| Ambient temperature | −40 … +65 °C (ventilated) |
| Standards | EN/IEC 60335-1/2-29, IEC 62109-1, ECE R10 (12 V) |
Compatibilities
Compatible with: Cerbo GX, Color Control GX, VE.Bus Smart Dongle, Digital Multi Control Panel, MK3-USB interface, BMV-712/SmartShunt monitors, VictronConnect app, and VRM portal. Does not have a second AC output (available from 3 kVA models).
The Victron MultiPlus C 12V 800VA 12/800/35-16 stands out for its reliability, efficiency, and intelligent energy management for compact 12 V systems.
