Victron Phoenix VE.Direct Inverter 12V 1200VA 12/1200
Modelo: Phoenix VE.Direct 12/1200- Sku: VICTINV061
- Vendor: Victron
Specifications
Product Description
The Victron Phoenix VE.Direct 12V 1200VA 12/1200 provides power and reliability to convert 12 V DC into 230 V AC with pure sine wave output. Its professional architecture and VE.Direct control allow configuration of battery thresholds, frequency, and alarms, while ECO mode minimizes standby consumption to maximize autonomy in caravans, boats, and off-grid solar systems.
Main Features
- Continuous power 1200 VA (≈1000 W at 25 °C) and peak power 2200 W for demanding startups.
- 12 V input (≈9.2–17 V DC) with configurable low voltage disconnect and restart.
- 230 V 50/60 Hz adjustable output; pure sine wave for sensitive electronics.
- VE.Direct port for parameterization and monitoring with VictronConnect (USB/Bluetooth).
- ECO mode: ultra-low standby consumption (≈1 W) with adjustable polling period.
- Comprehensive protections: short circuit, overload, overtemperature, high/low Vbat, and DC ripple.
Advantages or Benefits
- Starts loads with high peak (compact microwaves, light tools, small pumps) without drops.
- Stable grid quality that prevents buzzing, overheating, and failures in electronic equipment.
- Real battery savings thanks to its high efficiency and programmable ECO mode.
- Fine configuration to adapt the inverter to the needs of each installation.
- Simple integration with the Victron ecosystem for local or remote control and preventive maintenance.
Purpose or Applications
Recommended for campers and boats with medium consumption, mobile workshops, and off-grid solar systems that require sustained power and high startup capacity with advanced control.
Technical Specifications
| Continuous power | 1200 VA (≈1000 W at 25 °C) |
| Peak power | 2200 W |
| Input voltage | ≈9.2–17 V DC |
| Output | 230 V AC ±3 % | 50/60 Hz (adjustable) |
| Max efficiency | ≈92–93 % |
| No-load consumption | ≈8–10 W |
| Consumption in ECO mode | ≈1 W (default retry 2.5 s; adjustable) |
| Wave type | Pure sine wave |
| Connectivity | VE.Direct (USB/Bluetooth via accessories) |
| Protections | SC, overload, high T°, high/low Vbat, DC ripple |
| IP rating | IP21 |
| Dimensions | ≈117 × 232 × 327 mm |
| Weight | ≈7.4 kg |
| Standards | EN/IEC 62109-1, EMC; ECE R10 |
Compatibilities
Compatible accessories: VE.Direct to USB cable, VE.Direct to Bluetooth Smart (dongle), Filax switch, BMV/SmartShunt monitors, remote On/Off switch, and VictronConnect app. Use with 12 V batteries and suitable DC protections.
The Victron Phoenix VE.Direct 12V 1200VA 12/1200 combines power, efficiency, and intelligent control for mobile and solar applications that demand professional performance with pure sine wave output.
