Victron Phoenix Smart Inverter 12V 2000VA 12/2000
Modelo: Phoenix Smart 12/2000- Sku: VICTINV067
- Vendor: Victron
Specifications
Product Description
The Victron Phoenix Smart Inverter 12V 2000VA 12/2000 increases power in 12 V systems, offering 2000 VA continuous (1600 W at 25 °C) and a peak of 4000 W to start demanding loads. It maintains a pure sine wave and adds full control via Bluetooth and VE.Direct port, ECO mode with ultra-low consumption, and a programmable relay to automate alarms or generator start. Its professional design and protective electronics ensure stable operation in caravans, boats, and off-grid solar systems.
Main Features
- Continuous power: 2000 VA (1600 W at 25 °C) with a peak of 4000 W.
- 12 VDC input (9.3–17 V) and 230 VAC output ±2% at 50/60 Hz.
- Integrated Bluetooth for advanced configuration from the VictronConnect app.
- VE.Direct for monitoring/logging and connection to GX equipment.
- ECO mode: standby consumption of 0.6 W; idle consumption 8 W.
- Comprehensive electronic protections and IP21; temperature -40 to +65 °C.
Advantages or Benefits
- Quality energy for sensitive electronics, chargers, tools, and appliances without noise or voltage drops.
- Reliable start of high inrush loads (pumps, compressors) thanks to double instant power.
- Battery savings with ECO mode and dynamic disconnection configurable by voltage and load.
- Simple automation with the programmable relay and remote on/off input.
- Quick integration with battery monitors and gateways for local or remote control.
Purpose or Applications
Designed for high-demand campers, boats with intermittent consumption, site cabins, food trucks, off-grid 12 V solar installations, and backup systems where high starting power with great voltage and frequency stability is required.
Technical Specifications
| Model | Phoenix Smart 12/2000 |
| Continuous power | 2000 VA (1600 W at 25 °C) |
| Peak power | 4000 W |
| Input voltage | 12 VDC (9.3–17 V) |
| Output | 230 VAC ±2% | 50/60 Hz |
| Max efficiency | ≈92 % |
| Idle consumption | 8 W (ECO: 0.6 W) |
| Communications | Bluetooth, VE.Direct |
| Programmable relay | Yes (alarm/undervoltage/generator start) |
| Protections | Short circuit, overload, high/low battery voltage, overtemperature, 230 V on output, high ripple |
| Operating temperature | -40…+65 °C |
| Protection rating | IP21 |
| Dimensions | 485×219×125 mm |
| Weight | ≈13 kg |
| Parallel/Three-phase | No |
| Certification | ECE R10 |
Compatibilities
Integrates with BMV-712 Smart, VE.Direct to USB, Phoenix Inverter Control panel, Cerbo/Color Control GX, and Filax transfer switch for fast transfer between grid and inverter. Compatible with properly wired 12 V battery banks and suitable DC protections.
With the Victron Phoenix Smart Inverter 12V 2000VA 12/2000 you get power, control, and safety for high-performance mobile and solar applications.
