Victron Phoenix VE.Direct Inverter 12V 250VA 12/250
Modelo: Phoenix VE.Direct 12/250- Sku: VICTINV057
- Vendor: Victron
Specifications
Product Description
The Victron Phoenix VE.Direct 12V 250VA 12/250 is a pure sine wave inverter designed to safely power 230 V equipment from 12 V systems. Thanks to its toroidal transformer topology, it offers high reliability in caravans, boats, and small off-grid solar installations. Its VE.Direct port allows configuration of critical parameters and real-time monitoring, while ECO mode minimizes consumption when there is no load.
Main Features
- Continuous power: 250 VA (200 W at 25 °C / 175 W at 40 °C). Instantaneous peak of 400 W.
- Battery input range: 9.2–17 V DC with fully adjustable low voltage disconnect and restart.
- 230 V AC output 50/60 Hz adjustable; pure sine wave for sensitive electronics.
- VE.Direct port for configuration, monitoring, and connection to VictronConnect (USB/Bluetooth).
- ECO mode: ultra-low standby consumption (≈0.8 W) and adjustable retry.
- Comprehensive protection: short circuit, overload, overtemperature, high/low voltage, and high “DC ripple”.
Advantages or Benefits
- Stable and safe power that protects sensitive equipment against harmonics and instabilities.
- Real energy savings with ECO mode, ideal for extending battery autonomy.
- Custom configuration (voltage/frequency, LVD thresholds) to adapt to each system.
- High start-up power to switch on difficult loads such as LED converters or light tools.
- Simple integration with monitoring and diagnostics via app and Victron accessories.
Purpose or Applications
Perfect for small loads in caravans, camper vans, boats, telecom, and basic solar kits (chargers, routers, LED lighting, laptops via chargers). Also useful as occasional backup in mobile workshops.
Technical Specifications
| Continuous power | 250 VA (200 W at 25 °C / 175 W at 40 °C) |
| Peak power | 400 W |
| Input voltage | 9.2–17 V DC |
| Output | 230 V AC ±3% | 50/60 Hz ±0.1% (adjustable) |
| Max efficiency | ≈87 % |
| No-load consumption | ≈4.2 W |
| ECO consumption | ≈0.8 W (default retry 2.5 s; adjustable) |
| Wave type | Pure sine wave |
| Connectivity | VE.Direct (USB/Bluetooth via accessories) |
| Protection | SC, overload, high T°, high/low Vbat, DC ripple |
| Operating temperature | -40…+65 °C (with power reduction >25 °C) |
| AC socket | Schuko / IEC-320 depending on version |
| IP | IP21 |
| Dimensions | 86×165×260 mm |
| Weight | 2.4 kg |
| Standards | EN/IEC 62109-1, EMC; ECE R10-4 |
Compatibilities
Recommended accessories: VE.Direct to USB, VE.Direct to Bluetooth Smart (Smart Dongle), Filax automatic switch, BMV battery monitor, remote On/Off switch, VictronConnect app. Integrable with DC protections and suitable 12 V battery banks.
The Victron Phoenix VE.Direct 12V 250VA 12/250 offers professional reliability, efficiency, and advanced control for small systems that require pure sine wave quality.
