Victron Phoenix Smart Inverter 24V 1600VA 24/1600
Modelo: Phoenix Smart 24/1600- Sku: VICTINV078
- Vendor: Victron
Specifications
Product Description
The Victron Phoenix Smart Inverter 24V 1600VA 24/1600 converts 24 VDC to 230 VAC with a stable pure sine wave, safe for sensitive equipment. It features Bluetooth for configuration and monitoring via the VictronConnect app, a VE.Direct port for integration with GX devices, and a programmable relay that automates alarms or generator start. Its 3000 W peak, high efficiency, and ECO mode with ultra-low consumption make it a robust solution for campers, boats, and off-grid 24 V solar systems.
Main Features
- Continuous power: 1600 VA (≈1300 W at 25 °C); 3000 W peak for loads with high inrush.
- Input 24 VDC (typical range 19–33 V) and output 230 VAC ±2% at 50/60 Hz.
- Integrated Bluetooth and VE.Direct for configuration, logging, and remote control.
- ECO mode with standby consumption of ≈0.6 W; no-load consumption ≈8 W.
- Programmable relay and remote on/off interface for simple automation.
- Comprehensive electronic protections and professional IP21 construction.
Advantages or Benefits
- Pure sine wave that protects delicate electronics (IT, chargers, light medical equipment).
- Reliable start of pumps or compressors thanks to the 3000 W peak.
- Maximum autonomy: high efficiency and ECO reduce consumption when there is no load.
- App management: adjustment of alarms, cut-off voltages, ECO, and remote start.
- Quick integration with battery monitors and Victron supervision systems.
Purpose or Applications
Ideal for 24 V caravans and campers, recreational boating, technical cabins, food trucks, and off-grid homes that require stable 230 V for LED lighting, efficient refrigerators, light tools, and sensitive electronics.
Technical Specifications
| Model | Phoenix Smart 24/1600 |
| Continuous power | 1600 VA (≈1300 W at 25 °C) |
| Peak power | 3000 W |
| Input voltage | 24 VDC (≈19–33 V) |
| Output | 230 VAC ±2% | 50/60 Hz |
| Max. efficiency | ≈94 % |
| No-load consumption | ≈8 W (ECO ≈0.6 W) |
| Communications | Bluetooth, VE.Direct |
| Programmable relay | Yes (alarm/undervoltage/generator start) |
| Protections | Short circuit, overload, high/low battery voltage, overtemperature, 230 V at output, high ripple |
| Operating temperature | -40…+65 °C |
| Protection rating | IP21 |
| Dimensions | 485 × 219 × 125 mm |
| Weight | ≈12 kg |
| Parallel/Three-phase | No |
| Certification | ECE R10 |
Compatibilities
Compatible with BMV-712 Smart monitors, VE.Direct-USB interface, Phoenix Inverter Control panel, Cerbo/Color Control GX, and Filax transfer switch. Requires appropriate DC wiring and protections (MEGA/MIDI fuses, disconnect switch, DC circuit breaker) for 24 V battery banks.
The Victron Phoenix Smart Inverter 24V 1600VA 24/1600 provides stable power, intelligent control, and maximum efficiency for your 24 V energy projects.
