Victron Phoenix VE.Direct Inverter 24V 500VA 24/500

Modelo: Phoenix VE.Direct 24/500

Sku: VICTINV071
Vendor: Victron

€230,66 EUR

€173,00 EUR

Tax included.

Shipping calculated at checkout.

In stock!

Spend €150,00 to FREE SHIPPING

Victron Phoenix VE.Direct 24V 500VA 24/500 supplies stable pure sine wave for 24 V systems. With 900 W peak, VE.Direct port, ultra-low ECO mode, and complete protections, it is ideal for caravans, marine, and off-grid solar.

Product variants

Quantity

I agree with the Terms and Conditions.

Purchase with Secure Payment

Specifications

Product Description

The Victron Phoenix VE.Direct 24V 500VA 24/500 safely converts energy from a 24 V battery into 230 V AC pure sine wave to power sensitive equipment. Its professional architecture with toroidal transformer and digital control ensures reliability, while the VE.Direct port allows configuration and monitoring of the device’s behavior from the VictronConnect app via USB cable or Bluetooth Smart Dongle. With peaks of 900 W and an ECO mode that drastically reduces standby consumption, it is a balanced solution for campers, boats, and small off-grid solar installations that demand performance and efficiency.

Main Features

Continuous power: 500 VA (≈400 W at 25 °C) with peak power 900 W for demanding startups.
24 V input window: ≈18.4–34 V DC; fully adjustable low/high voltage thresholds and recovery.
230 V AC 50/60 Hz configurable output; pure sine wave suitable for sensitive electronics and light motors.
VE.Direct port for configuration, event logging, and real-time monitoring.
ECO mode with standby consumption ≈1 W and adjustable polling period to maximize autonomy.
Protections: short circuit, overload, overtemperature, high/low voltage, and DC ripple.

Advantages or Benefits

Stable power that prevents buzzing, flickering, and failures in chargers, routers, TVs, light tools, or LED lighting.
Greater battery bank autonomy thanks to its high efficiency and ultra-low ECO mode.
Fine parameterization (frequency, output voltage, LVD/recovery) to adapt to each installation.
Simple integration with the Victron ecosystem for diagnostics, maintenance, and control from mobile or computer.
Robust and compact format, perfect for confined spaces and mobile applications.

Purpose or Applications

Suitable for caravans, camper vans, recreational boats, small-scale off-grid photovoltaic systems, telecom, and instrumentation equipment that require a stable 230 V network without penalizing consumption.

Technical Specifications

Continuous power	500 VA (≈400 W at 25 °C)
Peak power	900 W
Input voltage	≈18.4–34 V DC (adjustable LVD/recovery threshold)
Output	230 V AC ±3 % \| 50/60 Hz ±0.1 % (adjustable)
Max. efficiency	≈90 %
No-load consumption	≈6 W
ECO mode consumption	≈1 W (configurable polling period)
Wave type	Pure sine wave
Connectivity	VE.Direct (USB / Bluetooth via accessories)
Protections	SC, overload, high T°, high/low Vbat, DC ripple
Operating temperature	-40…+65 °C (derating >25 °C)
IP rating	IP21
Dimensions	86 × 165 × 260 mm
Weight	≈3.2 kg
Standards	EN/IEC 62109-1, EMC; ECE R10

Compatibilities

Compatible accessories: VE.Direct to USB, VE.Direct to Bluetooth Smart Dongle, Filax automatic switch, BMV/SmartShunt battery monitors, On/Off remote switch, and VictronConnect app. Use with 24 V batteries and suitable DC protections.

The Victron Phoenix VE.Direct 24V 500VA 24/500 combines useful power, advanced control, and maximum efficiency for mobile and solar applications that demand professional quality.
