Victron Phoenix VE.Direct Inverter 48V 375VA 48/375
Modelo: Phoenix VE.Direct 48/375- Sku: VICTINV083
- Vendor: Victron
Specifications
Product Description
The Victron Phoenix VE.Direct 48V 375VA 48/375 is a pure sine wave inverter for 48 V that combines useful power, high efficiency, and detailed control. It provides a stable 230 V output for sensitive equipment and loads with moderate start-up demand, while the VE.Direct port allows configuration of battery thresholds, frequency and output voltage, alarm logging, and performance monitoring from the VictronConnect app via USB cable or optional Bluetooth.
Main Features
- Continuous power: 375 VA (≈300 W at 25 °C / ≈260 W at 40 °C) with peak power 700 W.
- 48 V input: ≈36.8–62 V DC with fully adjustable low voltage disconnect and recovery.
- 230 V 50/60 Hz adjustable output; pure sine wave for electronics and small motors.
- VE.Direct for configuration, event logging, and real-time monitoring.
- ECO mode: standby consumption ≈1 W with configurable polling period to maximize autonomy.
- Comprehensive protections: short circuit, overload, overtemperature, high/low Vbat, and DC ripple.
Advantages or Benefits
- Stable grid supply that prevents flickering, noise, and failures in TVs, routers, chargers, and IT equipment.
- Energy savings thanks to high efficiency and ultra-low standby in ECO mode.
- Fine configuration to adapt the inverter to the actual usage profile and 48 V battery bank.
- Quick integration with the Victron ecosystem: BMV/SmartShunt monitor, Filax, remote control, and app.
Purpose or Applications
Recommended for campers and boats with a 48 V system, telecom and remote instrumentation, and small off-grid solar installations that require more power than the 250 VA model without sacrificing size or efficiency.
Technical Specifications
| Continuous power | 375 VA (≈300 W at 25 °C / ≈260 W at 40 °C) |
| Peak power | 700 W |
| Input voltage | ≈36.8–62 V DC (LVD/recovery adjustable) |
| Output | 230 V AC ±3 % | 50/60 Hz ±0.1 % (adjustable) |
| Max. efficiency | ≈90 % |
| No-load consumption | ≈5–6 W |
| ECO mode consumption | ≈1 W |
| Wave type | Pure sine wave |
| Connectivity | VE.Direct (USB/Bluetooth with accessories) |
| IP rating | IP21 |
| Dimensions | 86 × 165 × 260 mm |
| Weight | ≈3.0 kg |
| Environment | -40…+65 °C (derating >25 °C) |
| Protections | SC, overload, high T°, high/low Vbat, DC ripple |
Compatibilities
Accessories: VE.Direct–USB, VE.Direct–Bluetooth Smart Dongle, Filax automatic switch, BMV/SmartShunt battery monitors, On/Off remote switch, and VictronConnect app. Use with 48 V batteries and suitable DC protections.
The Victron Phoenix VE.Direct 48V 375VA 48/375 offers the ideal balance between power, efficiency, and control for compact and professional 48 V installations.
