Victron Phoenix Inverter VE.Direct 48V 800VA 48/800
Modelo: Phoenix VE.Direct 48/800- Sku: VICTINV085
- Vendor: Victron
Specifications
Product Description
The Victron Phoenix VE.Direct 48V 800VA 48/800 is designed for those who need more sustained power and a high start-up peak while maintaining a compact size and maximum efficiency. It converts 48 V DC into 230 V AC pure sine wave, protecting sensitive electronics and allowing operation of loads with high transient demands, such as small pumps, light compressors, or compact microwaves. Its VE.Direct port facilitates configuration and monitoring with VictronConnect, while ECO mode reduces consumption when there is no load, extending the autonomy of the battery bank.
Main Features
- Continuous power: 800 VA (≈650 W at 25 °C) and peak power of 1500 W.
- 48 V input: ≈36.8–62 V DC with fully configurable low/high voltage thresholds and recovery.
- 230 V output 50/60 Hz adjustable; pure sine wave for electronics and small motors.
- VE.Direct port for advanced configuration, alarm logging, and real-time monitoring.
- ECO mode: standby consumption ≈1 W with configurable polling period.
- Comprehensive protections: short circuit, overload, overtemperature, high/low Vbat, and DC ripple.
Advantages or Benefits
- Reliable start-up of loads with high peak without voltage drops or unwanted trips.
- Stable grid quality that prevents buzzing, overheating, and failures in sensitive equipment.
- Optimizes available energy thanks to its high efficiency and ultra-low standby.
- Flexible configuration to adapt to each application and consumption profile in 48 V.
- Quick integration with the Victron ecosystem for local or remote control and preventive maintenance.
Purpose or Applications
Recommended for campers and boats with a 48 V system, mobile workshops, and off-grid solar systems that require higher sustained power, high start-up capacity, and intelligent control without compromising efficiency.
Technical Specifications
| Continuous power | 800 VA (≈650 W at 25 °C) |
| Peak power | 1500 W |
| Input voltage | ≈36.8–62 V DC (LVD/recovery adjustable) |
| Output | 230 V AC ±3 % | 50/60 Hz ±0.1 % (adjustable) |
| Maximum efficiency | ≈92 % |
| No-load consumption | ≈7–9 W |
| ECO mode consumption | ≈1 W |
| Wave type | Pure sine wave |
| Connectivity | VE.Direct (USB/Bluetooth via accessories) |
| Protections | SC, overload, high T°, high/low Vbat, DC ripple |
| Operating temperature | -40…+65 °C (derating >25 °C) |
| IP rating | IP21 |
| Dimensions | 86 × 165 × 260 mm |
| Weight | ≈3.8 kg |
| AC connection | Schuko / IEC-320 depending on version |
Compatibilities
Recommended accessories: VE.Direct–USB, VE.Direct–Bluetooth Smart Dongle, Filax automatic switch, BMV/SmartShunt battery monitors, remote On/Off switch, and VictronConnect app. Use with 48 V batteries and DC protections sized to the power.
The Victron Phoenix VE.Direct 48V 800VA 48/800 combines start-up power, efficiency, and professional control for mobile and solar applications that demand high performance at 48 V.
