3 MPPT Solar Protections Kit 600V 40A Aurensol
Modelo: 3 MPPT Solar 600V 40A- Sku: WORLPRO049
- Vendor: WorldSunLight
Specifications
Product Description
The Kit Protections 3 MPPT Solar 600V 40A Aurensol is designed for photovoltaic installations with three high-current strings connected to three independent MPPTs. The per-string scheme provides each string with its own 600 V DC surge arrester (Type 2) and a 2P 40 A 800 VDC curve C photovoltaic circuit breaker, ensuring reliable disconnection in direct current and effective protection against transients. The IP65 enclosure with 18 modules integrates everything into a compact and sealed panel, with orderly DIN rail distribution to speed up assembly, inspection, and maintenance.
Main Features
- IP65 enclosure with 18 modules (1 row), robust for protected indoor or outdoor use.
- 3 × SPD DC 600 V Type 2 (2P), one for each string/MPPT.
- 3 × PV circuit breaker 2P 40 A 800 VDC curve C with specific DC breaking capacity.
- Selective topology per string that facilitates diagnosis and reduces downtime.
- Free space for disconnectors, gPV fuses, or SPD monitoring.
Advantages or Benefits
- Coordinated protection that preserves modules, cabling, and inverter electronics.
- Greater system availability thanks to independent tripping per string.
- Quick and maintainable installation with clean wiring and easy access to terminals.
- Compatibility with TOPCon/bifacial modules and MPPT inputs ≤600 Vdc and ≤40 A.
- Professional appearance and technical compliance in a single compact kit.
Purpose or Applications
Ideal for advanced residential self-consumption and small commercial/industrial use with three orientations or differentiated fields, when the current per string reaches ≤40 A and the field voltage is ≤600 Vdc.
Technical Specifications
| No. of MPPT / strings | 3 MPPT / 3 strings |
| Max. SPD voltage | 600 V DC |
| Surge protection | 3 × Type 2 · 2P · replaceable |
| Circuit breaker protection | 3 × 2P 40 A · 800 VDC · curve C |
| Enclosure | IP65 · 18 modules · 1 row |
| Application | DC protection per string towards each MPPT |
Kit Composition
- 1 × IP65 Sealed Panel HT-18WAYS 18 Modules 1 Row
- 3 × DC Surge Arrester XLSPD-PV 600V 2P
- 3 × Circuit Breaker XL7-63 PV 2P 40A 800VDC Curve C
Compatibilities
Usable as a DC panel prior to three MPPTs in inverters from Huawei, Sungrow, Solis, GoodWe, Fronius, SMA, SolaX, Salicru, etc., within ≤600 Vdc and ≤40 A per input. Suggested accessories: MC4 connectors, IP66/68 cable glands, DC load disconnectors, gPV fuses, terminal blocks, and safety labeling.
The Kit Protections 3 MPPT Solar 600V 40A Aurensol provides selective, robust, and ready-to-install protection for high-current three-string systems.
