RV-K Hose 3x2.5mm² 50m Black 0.6/1kV
Modelo: RV-K 3x2,5mm² 50m Negra- Sku: REVICAB024
- Vendor: Revi
Specifications
Product Description
The RV-K Hose 3x2.5mm² 50m Black 0.6/1kV is a flexible power cable designed for installations and maintenance where medium-length runs are required without waste. Its 2.5 mm² cross-section balances current capacity and ease of installation, making it ideal for power and lighting lines, branch circuits to panels, supply of pumps, and auxiliary equipment in solar systems. Class 5 copper conductor, XLPE insulation, and black PVC sheath provide reliable protection against weather, moisture, and typical mechanical stresses.
Main Features
- Class 5 copper conductor, 3 × 2.5 mm²: flexible and with low resistance.
- XLPE + PVC protection: excellent dielectric strength and resistance to UV and water.
- Rated voltage 0.6/1 kV for low voltage networks and service connections.
- Suitable for indoor, outdoor, and buried use, flame retardant.
- Typical service temperature: up to 90 °C at the conductor in continuous operation.
- 50 m coil reduces waste and facilitates transport on site.
Advantages or Benefits
- Lower voltage drop and higher current capacity than 1.5 mm² in the same flexible format.
- Quick installation: favorable bending radii, ideal for conduits with curves and compact panels.
- High durability outdoors thanks to the sheath resistant to UV and moisture.
- Safety and reliability due to high-performance XLPE insulation.
- 50 m format perfect for renovations, repairs, and small extensions without excess stock.
Purpose or Applications
Recommended for power and lighting circuits in homes, businesses, and light industry, for supplying pool filters, irrigation pumps, aerothermal systems, and auxiliary equipment for photovoltaic inverters. Suitable for installation in embedded or exposed conduit, cable duct, cable tray, and buried trench with sand bed and marking.
Technical Specifications
| Type | RV-K |
| Cross-section / number of conductors | 3 × 2.5 mm² |
| Conductor | Class 5 electrolytic copper (flexible) |
| Insulation | XLPE (cross-linked polyethylene) |
| Sheath | Black PVC, resistant to UV and moisture |
| Rated voltage | 0.6/1 kV |
| Service temperature | Up to 90 °C at conductor (continuous) |
| Installation | Indoor, outdoor, buried, conduit, duct, or tray |
| Reaction to fire (CPR) | Usual commercial classification in RV-K (see batch marking) |
| Coil length | 50 m |
| Reference standards | IEC 60502-1 / UNE 21123-2 |
Compatibilities
Compatible with standard conduits, cable glands, connectors, and trays for 2.5 mm². Useful as a service connection to panels, luminaires, small/medium motors, and auxiliary equipment. Accessories not included.
The RV-K Hose 3x2.5mm² 50m Black 0.6/1kV offers the perfect balance between capacity, flexibility, and format for maintenance work and new solar and electrical installations.
