RZ1-K Green Hose 3x1.5mm² 50M Halogen Free 0.6/1kV
Modelo: RZ1-K Verde 3x1.5mm² 50M- Sku: REVICAB032
- Vendor: Revi
Specifications
Product Description
The RZ1-K Green Hose 3x1.5mm² 50M Halogen-Free 0.6/1kV is a flexible low-voltage multipolar cable designed for safe installations in residential, commercial, industrial, and photovoltaic plant balance of system (AC side). Its triple class 5 copper conductor facilitates installation in conduits and trays; the XLPE insulation ensures thermal stability at 90 °C and the LSZH sheath minimizes the emission of smoke and corrosive gases. With CPR Cca-s1b,d1,a1 certification, it meets safety requirements for public spaces and civil works.
Main Features
- Rated voltage 0.6/1 kV; test voltage 3.5 kV.
- Flexible class 5 copper conductors, cross-section 3×1.5 mm².
- XLPE insulation and LSZH sheath (halogen-free, low smoke emission).
- Continuous conductor service at 90 °C (short-circuit 250 °C/5 s).
- Installation indoors, outdoors, on tray, in conduit, or buried.
- Professional format: 50 m roll for construction and maintenance.
Advantages or Benefits
- CPR Safety: very low smoke opacity and acidity.
- Superior manageability due to class 5 conductor and reduced bending radius.
- Versatility for lighting, socket, control, and general service circuits.
- Reliability and extended service life thanks to XLPE insulation.
- Productivity: the 50 m roll reduces splices and installation time.
Purpose or Applications
Ideal for lighting and power wiring in homes, offices, and commercial premises; distribution and control in warehouses; auxiliary lines in solar installations on alternating current. Suitable for tray, corrugated conduit, or buried ducts in accordance with REBT/ITC-BT.
Technical Specifications
| Designation | RZ1-K (AS) · XLPE/LSZH |
| No. of conductors | 3 (without protective conductor) |
| Cross-section | 3 × 1.5 mm² |
| Conductor | Class 5 copper (flexible) |
| Rated voltage | 0.6/1 kV |
| Test voltage | 3.5 kV |
| Service temperature | −15…+90 °C (250 °C/5 s in short-circuit) |
| Conductor resistance (20 °C) | ≈ 12.1 Ω/km per conductor |
| Reaction to fire (CPR) | Cca-s1b,d1,a1 |
| Standard | UNE 21123-4 |
| Sheath color | Green |
| Presentation | 50 m roll |
Compatibilities
Compatible with cable glands, ferrules, and terminals for 1.5 mm², as well as with standardized conduits (tube, tray, trench). Select protections and cross-section according to REBT, admissible currents, and voltage drop calculation.
The RZ1-K Green Hose 3x1.5mm² 50M Halogen-Free 0.6/1kV combines CPR safety, flexibility, and performance for reliable and durable low-voltage wiring.
