RZ1-K Green Hose 3x2.5mm² 100M Halogen Free 0.6/1kV
Modelo: RZ1-K Verde 3x2.5mm² 100M- Sku: REVICAB035
- Vendor: Revi
Specifications
Product Description
The RZ1-K Green Hose 3x2.5mm² 100M Halogen-Free 0.6/1kV is a flexible multipolar cable designed for distribution circuits and general services in low voltage applications that require maximum safety and reliability. It incorporates three class 5 copper conductors of 2.5 mm² with XLPE insulation (service at 90 °C) and a LSZH halogen-free sheath, which drastically reduces the opacity and toxicity of smoke in case of fire. Its CPR Cca-s1b,d1,a1 certification makes it suitable for public buildings, unique buildings, industry, and photovoltaic plant balance of system (AC side). The 100 m roll format streamlines new construction, renovations, and maintenance, minimizing splices and installation time.
Main Features
- Rated voltage 0.6/1 kV; test voltage 3.5 kV.
- Conductors: 3 × 2.5 mm² class 5 copper (high flexibility).
- Insulation: XLPE (90 °C); sheath: LSZH halogen-free.
- Fire reaction: CPR Cca-s1b,d1,a1 (low smoke opacity and acidity).
- Versatile use: indoor, outdoor, on tray, in conduit, or buried.
- Continuous 100 m roll for clean runs without splices.
Advantages or Benefits
- Safety in buildings and civil works: very low smoke opacity/toxicity, halogen-free.
- Quick installation: class 5 conductors with favorable bending radii.
- Efficiency and balance between current capacity and cost in 2.5 mm².
- Thermal and mechanical durability thanks to XLPE insulation.
- Compatibility with standardized REBT fittings and conduits.
Purpose or Applications
Lighting and power circuits, general outlets in residential and tertiary buildings, distribution and control in warehouses, auxiliary lines in solar installations (AC), and runs in tray, corrugated conduit, or buried ducts where CPR Cca is required.
Technical Specifications
| Designation | RZ1-K (AS) |
| Standard | UNE 21123-4 |
| Number of conductors | 3 |
| Section | 3 × 2.5 mm² |
| Conductor | Class 5 copper (flexible) |
| Insulation | XLPE (90 °C service / 250 °C, 5 s short-circuit) |
| Sheath | Polyolefin LSZH, halogen-free |
| Rated voltage | 0.6/1 kV |
| Test voltage | 3.5 kV |
| Conductor resistance (20 °C) | ≈ 7.41 Ω/km per conductor |
| Thermal range | −15…+90 °C (conductor) |
| Fire reaction (CPR) | Cca-s1b,d1,a1 |
| Sheath color | Green |
| Presentation | 100 m roll |
Compatibilities
Accepts terminals and ferrules for 2.5 mm², metric cable glands, and standardized conduits (tube, tray, trench). Select protections and section according to REBT/ITC-BT, admissible currents, and voltage drop calculation.
The RZ1-K Green Hose 3x2.5mm² 100M Halogen-Free 0.6/1kV combines CPR safety, flexibility, and a professional format for reliable and durable low voltage wiring.
