Inline Meter SolarEdge MTR 240 3PC1-D-A-MW with Integrated CTs

Product Description

The SolarEdge Inline Meter MTR 240 3PC1-D-A-MW is a three-phase energy meter with integrated current transformers, designed for photovoltaic installations with SolarEdge inverters. Its main function is to facilitate export control, energy consumption management, and integration with Smart Energy devices. With RS485 or wireless communication via the SolarEdge Home network, this device offers a compact, precise, and easy-to-install solution on a DIN rail.

Main Features

• Three-phase measurement: up to 65 A per phase with integrated CTs.
• Communication: RS485 Modbus or SolarEdge Home wireless network (863–870 MHz).
• Direct installation: compact design for DIN rail without external CTs.
• High accuracy: ±1 % in active energy (Class B EN50470 / Class 1 IEC62053-21).
• Total integration: with SolarEdge inverters and Smart Energy devices.
• Quick mounting: LCD display, configurable pulses, and reduced size.

Advantages or Benefits

• Allows real-time visualization and recording of consumption, production, and exported energy.
• Prevents unwanted surpluses thanks to its dynamic export limitation function.
• Simplifies installation with integrated transformers and no additional wiring.
• Compatible with residential and commercial environments up to 65 A per phase.
• Facilitates energy management through the SolarEdge app and platform.

Purpose or Applications

This meter is intended for three-phase photovoltaic installations that use SolarEdge Home inverters with zero export functions, load balancing, consumption management, or integration with contactors and EV chargers. Its use is ideal in homes, small businesses, and commercial projects that require intelligent energy control.

Technical Specifications

Compatibilities

This product is compatible with: SE-ANT-ENET-HB-01 (external antenna for wireless communication), and SolarEdge Home three-phase inverters with firmware version 4.14xx or higher.

SolarEdge Inline Meter MTR 240 3PC1-D-A-MW is a professional solution for demanding renewable energy projects. It increases autonomy, optimizes space, and improves the efficiency of your installation.
