MPPT Controller TBB Power SP250-70 250V 70A 24/48V

Modelo: SP250-70

Sku: TBBREGU002
Vendor: TBB

€772,69 EUR

€618,15 EUR

Tax included.

Shipping calculated at checkout.

In stock!

Spend €150,00 to FREE SHIPPING

TBB SP250-70 MPPT Regulator of 250 V / 70 A for 24/48 V. Up to 5.4 kW PV, MPPT range 65–245 V, 365-day datalogger, RS485, and forced ventilation for continuous operation in demanding climates.

Product variants

Quantity

I agree with the Terms and Conditions.

Purchase with Secure Payment

Specifications

Product Description

The MPPT Controller TBB Power SP250-70 250 V 70 A 24/48 V offers higher input voltage and charging current for systems that require longer cables and higher power PV arrays. With a tracking range of 65–245 V, it supports up to 2.7 kW (24 V) or 5.4 kW (48 V) of photovoltaic power, maintaining a 365-day data log, RS485 communication, and TBB II algorithm for lead-acid and lithium batteries.

Main Features

70 A charging for 24/48 V battery banks.
PV input up to 250 V Voc; MPPT range 65–245 V.
Admissible PV power: 2.7 kW (24 V) / 5.4 kW (48 V).
Efficiency up to 98 % and MPPT efficiency ≥ 99.9 %.
Forced ventilation for continuous operation and longer service life.
LED+LCD display, RS485, dry contact, and 365-day datalogger.

Advantages or Benefits

Longer cabling and reduced losses thanks to the 250 V PV bus.
Fast battery charging due to its high 70 A current.
Protection and care for AGM/GEL/open lead-acid and LiFePO₄ with dedicated profiles.
Precise tracking that maintains production even with partial shading and thermal changes.

Purpose or Applications

Off-grid and medium/high power self-consumption at 24/48 V: homes, businesses, telecom, technical cabins, and backup systems where high PV voltage and 70 A charging are required.

Technical Specifications

Model	SP250-70
Battery voltage	24 V / 48 V
Charging current	70 A
Max PV Voc	250 V
MPPT range	65–245 V
Admissible PV power	2.70 kW (24 V); 5.40 kW (48 V)
Max charging power	2.06 kW (24 V); 4.12 kW (48 V)
Max PV Isc	80 A
Max efficiency	≈98 %
MPPT efficiency	≥ 99.9 %
Charging voltages	Absorption 28.8/57.6 V; Float 27/54 V
Communication	RS485, dry contact
Data logging	365 days
Cooling	Forced ventilation
Protection	IP21
Dimensions	352.2×293×116.2 mm
Weight	7.8 kg
Operating temp.	-25 °C…+60 °C (derating >40 °C)
Standards	EN61000-6-1/6-3, EN62109-1

Compatibilities

Compatible with AGM/GEL/open lead-acid and LiFePO₄ batteries of 24/48 V with BMS. Supports PV strings in series ensuring Voc ≤ 250 V and appropriate DC protections (fuses, disconnectors, SPD) according to regulations.

The MPPT Controller TBB Power SP250-70 250 V 70 A 24/48 V combines high input voltage with high charging capacity for robust and efficient solar systems.
