MPPT Charge Controller Victron SmartSolar 150/100-TR VE.Can 12/24/48V 100A Bluetooth

Modelo: SmartSolar 150/100-TR VE.Can

Sku: VICTREG031
Vendor: Victron

€649,88 EUR

€519,91 EUR

Tax included.

Shipping calculated at checkout.

In stock!

Spend €150,00 to FREE SHIPPING

Victron SmartSolar MPPT Charge Controller 150/100-TR VE.Can 12/24/48V 100A Bluetooth delivers 100 A with ultra-fast MPPT. VE.Can for synchronizing up to 25 units, Bluetooth, programmable relay, and IP43.

Product variants

Quantity

I agree with the Terms and Conditions.

Purchase with Secure Payment

Specifications

Product Description

The MPPT Charge Controller Victron SmartSolar 150/100-TR VE.Can 12/24/48V 100A Bluetooth is Victron's reference for medium and large photovoltaic installations that require high charging current and higher voltage strings. With MPPT 150 V/100 A, VE.Can communication to synchronize multiple controllers, and integrated Bluetooth for configuration and logging via VictronConnect, it offers precise and scalable battery management in 12/24/48 V systems (36 V selectable by software). Its ultra-fast MPP tracking algorithm maximizes energy capture even with variable irradiance or partial shading, while the high-efficiency electronics operate without a fan and with very low self-consumption.

Main Features

MPPT 150 V / 100 A: supports up to 150 Vdc open circuit (145 V in operation) and delivers 100 A to the battery.
Admissible PV power (safe automatic limitation): ≈ 1,450 W (12 V) / ≈ 2,900 W (24 V) / ≈ 4,350 W (36 V) / ≈ 5,800 W (48 V).
Converter efficiency up to 98%, fanless design, and very low self-consumption.
Programmable multi-stage charging algorithm with BatteryLife, thermal compensation, and battery recovery from 0 V.
Connectivity: VE.Can, VE.Direct, and Bluetooth; programmable relay and remote on/off input.
Parallelization and synchronization of up to 25 controllers via VE.Can (or up to 10 via Bluetooth).

Advantages or Benefits

Higher daily yield compared to PWM or slow MPPT, thanks to ultra-fast MPP tracking and optimal point detection under partial cloud cover.
Protects and extends the life of the battery bank by avoiding deep discharges and adjusting voltages according to temperature.
True scalability: adding controllers and synchronizing them via VE.Can allows for expansion without redoing the installation.
Total control from a mobile device or a GX system: configuration, history, alarms, and OTA updates.

Purpose or Applications

Ideal for high-demand off-grid homes, self-consumption with batteries, professional marine, telecom, and small commercial/industrial installations requiring 100 A and strings up to 150 V, with centralized monitoring and high reliability.

Technical Specifications

Battery voltage	12/24/48 V automatic (36 V by software)
Charging current	100 A
Admissible PV power	≈ 1450 / 2900 / 4350 / 5800 W (12/24/36/48 V)
Max PV Voc	150 V absolute (145 V at startup/operation)
Max efficiency	Up to 98%
Communications	VE.Can, VE.Direct, Bluetooth
Programmable relay	Contacts for alarm/generator start
Parallelization	Up to 25 via VE.Can / 10 via Bluetooth
Degree of protection	IP43 electronics / IP22 connections
Dimensions (TR)	185 × 250 × 95 mm
Weight	≈ 3 kg
Operating temperature	−30 °C to +60 °C (derating > 40 °C)
Standards	EN/IEC 62109-1, UL 1741, CSA C22.2

Compatibilities

Accessories and ecosystem: pluggable LCD display, Smart Battery Sense, SmartShunt / BMV-712 Smart, Cerbo GX and GX family (VE.Can/VE.Direct), VE.Direct-USB cables, suitable DC fuses and protections.

The MPPT Charge Controller Victron SmartSolar 150/100-TR VE.Can 12/24/48V 100A Bluetooth combines power, scalability, and intelligent control to extract maximum performance and protect your storage system.
