Tubular Terminal Sofamel 2.5 mm² M6 T-2.5/6
Modelo: T-2,5/6- Sku: SOFAACC022
- Vendor: Sofamel
Specifications
Product Description
The Sofamel Tubular Terminal 2.5 mm² M6 T-2.5/6 is a tinned electrolytic copper connector designed to terminate 2.5 mm² conductors with M6 screws. Its finish provides low contact resistance and excellent protection against corrosion, while the inspection hole allows verification of conductor insertion before crimping. It is a reliable, robust terminal compliant with standards, intended for industrial and residential installations where electrical continuity and safety are priorities.
Main Features
- Cable cross-section: 2.5 mm² (flexible or rigid copper).
- Mounting hole: M6 for standard screw/bolt.
- Material: electrolytic copper with tinned finish for corrosion resistance.
- Inspection hole to verify conductor insertion depth.
- Tubular design that optimizes contact surface and thermal dissipation.
- Complies with IEC 61238-1-1 for compression connections.
Advantages or Benefits
- Stable, low-loss electrical conduction to improve system efficiency.
- Protective tinning that minimizes oxidation in humid or vibrating environments.
- Quick and repeatable assembly with standard crimping tool; reduced field installation time.
- Visual inspection of the conductor to prevent incomplete crimps.
- Long service life in panels, protections, and terminals thanks to its robust construction.
Purpose or Applications
Suitable for electrical panels, connections to terminals and busbars, battery protection, automation, photovoltaic solar, industrial vehicles, and light marine applications. Ideal for small-gauge connections where a reliable termination on M6 screw is required.
Technical Specifications
| Model | T-2.5/6 |
| Type | Tinned copper tubular terminal |
| Conductor cross-section | 2.5 mm² |
| Screw hole | M6 |
| Crimping compatibility | Hexagonal/oval die according to IEC 61238-1-1 |
| Inspection hole | Yes |
| Standard | IEC 61238-1-1 (compression connections) |
| Finish | Tinned (Sn) anti-corrosion |
| Material | Electrolytic copper |
Compatibilities
Direct compatibility: 2.5 mm² copper cables; terminals and busbars with M6 screw; circuit breakers/disconnectors with M6 ring connection.
Compatible accessories: heat shrink sleeves, anti-oxidant grease, M6 washers and nuts, compression crimping tools for tubular terminals.
The Sofamel Tubular Terminal 2.5 mm² M6 T-2.5/6 offers maximum safety and conductivity in compact, professional connections.
