2 MPPT Solar Protections Kit 600V 50A Aurensol

Product Description

The Kit Protections 2 MPPT Solar 600V 50A Aurensol provides in a single set all the necessary direct current protections when working with two high-intensity photovoltaic strings and two independent MPPT inputs. The branch-based architecture, with its own surge arrester and 800 VDC photovoltaic circuit breaker, ensures selectivity, fast diagnostics, and maximum service continuity. The IP65 enclosure with 12 modules offers a compact, sealed, and ready-to-install panel that reduces engineering time and selection errors, maintaining a professional appearance and additional space for future expansions.

Main Features

• Sealed IP65 panel with 12 modules (1 row), suitable for protected indoor or outdoor installation.
• 2 × DC surge arrester 600 V Type 2 (2P), one for each string/MPPT.
• 2 × photovoltaic circuit breaker 2P 50 A 800 VDC curve C with DC breaking capacity.
• String-based topology: greater selectivity and ease of maintenance.
• DIN rail mounting with space reserved for disconnectors, gPV fuses, or monitoring.

Advantages or Benefits

• Coordinated protection: SPD + circuit breaker per branch to limit faults and protect the inverter.
• Service continuity: simple diagnostics and minimal downtime due to selective tripping.
• Quick installation: material selection resolved and orderly distribution.
• Scalability: free space to integrate measurement or load disconnecting.
• Wide compatibility: suitable for MPPT up to 600 Vdc and currents ≤50 A per input.

Purpose or Applications

Recommended for advanced residential self-consumption and small commercial/industrial use with two orientations or separated strings, high-current TOPCon or bifacial modules, and two independent MPPTs. Use it as a DC protection panel before each MPPT when the field voltage is ≤600 Vdc and the branch current is ≤50 A.

Technical Specifications

Kit Composition

• 1 × Sealed Panel IP65 HT-12WAYS 12 Modules 1 Row
• 2 × DC Surge Arrester XLSPD-PV 600V 2P
• 2 × Circuit Breaker XL7-63 PV 2P 50A 800VDC Curve C

Compatibilities

Usable with inverters from brands such as Huawei, Sungrow, Solis, GoodWe, Fronius, SMA, SolaX, or Salicru, respecting 600 Vdc and ≤50 A per input. Recommended accessories: MC4 connectors, IP66/68 cable glands, disconnector
