Lorentz PS2-200 0.3kW IP68 MPPT Solar Controller

Product description

The Lorentz PS2-200 0.3 kW is a state-of-the-art solar controller designed for low-power pumping systems. It incorporates MPPT technology, battery discharge protection, and a fully sealed IP68 enclosure, making it an ideal solution for demanding environments. It is specially designed for Lorentz PS2-200 pumps, enabling efficient, safe, and autonomous control of solar pumping in off-grid installations.

Main features

• Maximum output power: 0.3 kW
• Maximum input voltage: 100 VDC (MPPT >34 VDC)
• IP68 protection rating: submersible or outdoor installation
• Maximum motor current: 11 A
• Inputs for sensors for level, dry well, pressure, switches
• Battery mode with deep discharge protection

Advantages or benefits

• Ideal for solar installations with very low water demand
• Allows operation with battery in areas of irregular irradiation
• Easy integration with sensors to automate pumping
• Optimized solar efficiency through MPPT
• Robust and compact design, suitable for intensive field use

Purpose or applications

The Lorentz PS2-200 is perfect for small solar projects in rural homes, family gardens, drip irrigation systems, or animal watering troughs. Thanks to its compact size and autonomy, it is an effective and economical solution for locations without access to the electrical grid or with basic water requirements.

Technical specifications

Compatibilities

This product is compatible with: PU200 C-SJ3-9, PU200 HRE-04, PU200 HRE-07, PU200 HRE-10, PU200 HRE-14, Well probe, Lorentz solar sensor, Level switch, Surge protection.

Lorentz PS2-200 0.3 kW is an efficient and economical option for automating water supply with solar energy. Compact, robust, and designed for demanding rural environments.
