Lorentz PS2-4000 4.0kW IP68 MPPT Solar Controller
Modelo: 07-000540 PS2-4000 Controller-4.0kVA- Sku: LOREACC005
- Vendor: Lorentz
Specifications
Product description
The Lorentz PS2-4000 4.0 kW is a high-performance solar controller with MPPT technology, IP68 protection, and maximum efficiency of 98%. It is the heart of the Lorentz PS2-4000 system and is responsible for managing the entire process of conversion, control, and protection of submersible or surface solar pumps. Designed for demanding environments, this equipment is ideal for professional pumping projects in agriculture, livestock, or rural supply.
Main features
- Output power 4.0 kW for high-demand solar pumps
- Integrated MPPT with a maximum input voltage of 375 VDC
- IP68 protection rating (submersible and watertight)
- Maximum efficiency of 98% and full system control
- Compatible with Lorentz sensors for level, pressure, dry well, etc.
- Built-in Sun Sensor for automatic solar radiation detection
Advantages or benefits
- Optimizes water production with dynamic maximum power point tracking
- Robust and durable design, ideal for remote and demanding installations
- Monitoring and configuration via PumpScanner Bluetooth app or Compass software
- Ready for hybrid connection with grid or generator via PowerPack
- Compatible with Lorentz protections and specialized probes
Purpose or applications
The PS2-4000 controller is designed for large-capacity solar pumping installations. It is ideal for agricultural drip or sprinkler irrigation systems, livestock with elevated tanks or troughs, potable water supply, and off-grid solar projects that require robustness, reliability, and consistent performance.
Technical specifications
| Power | 4.0 kW |
| Nominal voltage | Vmp >238 VDC / Voc max. 375 VDC |
| Format | IP68, submersible, vertical installation |
Compatibilities
This product is compatible with: PU4000 C-SJ3-32, PU4000 C-SJ5-25, PU4000 C-SJ8-15, PU4000 C-SJ17-4, PU4000 C-SJ30-2, PU4000 C-SJ42-2, PU4000 C-SJ60-1, PU4000 C-SJ60-2-2, PU4000 HRE-05HHL, PU4000 HRE-14HL, PU4000 HRE-32, PU4000 CS-F8-8, PU4000 CS-F16-3, PU4000 CS-F32-20-2, PU4000 CS-F42-10-1, PowerPack PP4000AC, Level switch, Surge protector, Well probe, Lorentz solar sensor.
Lorentz PS2-4000 4.0 kW is an advanced solar control solution for demanding pumping systems. It combines MPPT tracking technology, full protection, and complete compatibility with the Lorentz ecosystem.
