Lorentz PS2-600 0.7kW IP68 MPPT Solar Controller

Product description

The Lorentz PS2-600 0.7 kW is an intelligent solar controller with integrated MPPT technology, designed for low-power solar pumping systems. With IP68 protection, this device can be installed in wells or watertight boxes, and its compact, robust design makes it perfect for applications in remote areas. It includes full protection for the motor, the solar installation, and optionally for batteries.

Main features

• Output power: 0.7 kW
• Maximum input voltage: 150 VDC, MPPT from 68 VDC
• IP68 protection rating submersible and watertight
• System efficiency: up to 98 %
• Auxiliary inputs for sensors and external controllers
• Deep discharge protection (battery mode)

Advantages or benefits

• Efficient pump management in rural areas or locations without grid access
• Compatible with batteries and direct use with solar panels
• Easy to install and configure with mobile app or professional software
• Protects the pump and electrical system against overloads, reverse polarity, or extreme temperatures
• Standalone: starts and stops based on solar irradiation

Purpose or applications

This controller is designed for small solar pumping systems in rural homes, family gardens, drip irrigation systems, livestock drinking troughs, or installations with low water demand. Ideal for low-consumption solar projects where reliability, efficiency, and ease of use are required.

Technical specifications

Compatibilities

This product is compatible with: PU600 CS-17-1, PU600 C-SJ3-9, PU600 C-SJ5-8, PU600 C-SJ8-5, PU600 HRE-03, PU600 HRE-03H, PU600 HRE-04, PU600 HRE-04H, PU600 HRE-07, PU600 HRE-10, PU600 HRE-14, PU600 CS-F3-7, PU600 CS-F4-3, Level switch, Surge protection, PowerPack PP600H, Well probe, Lorentz solar sensor.

Lorentz PS2-600 0.7 kW is a reliable and efficient solution for small solar pumping systems, with full protection, MPPT technology, and robust design for demanding environments.
